VSD Pressure Transducer 25 bar

Specifications

1. Rating: 4-20mA / 0-25 Bar
2. Accuracy: 0.5%FS; 1%FS
3. Nonlinearity: Full span x 0.2%
4. Repeatability: Full span x .05%
5. Output: 4-20mA (two wire), 0-5V, 0-10V (three wire); 2mV/V, 3.3mV/V (PTS-210)
6. Input voltage:24(12~36)VDC (Amplifying signal), 10(6~12)VDC (mV output)
7. Operating temperature: -40~800C
8. Compensated temperature: 0~700C
9. Overload pressure:150%FS
10. Medium material: Stainless steel
11. Electric connector: Hirschman (DIN), M12, 4 pins, Bendix connector, grand cable (custom design)
12. Process connector: G1/4, G1/2, 1/2NPT, 1/4NPT, M12*1.5 (custom design)
